Product Details:

Place of Origin: CHINA
Brand Name: LEVER
Certification: CE
Model Number: LV-TB-V Series

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: 380000USD
Packaging Details: Wooden cases
Delivery Time: 90-120 DAYS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 SETS PER YEAR
Contact Now
Detailed Product Description
Machine Type: Glass Tempering Furnace Usage: Automotive Rear Glass, Tempered Glass, Safety Glass
Forming Way: Gravity Toolings Or Pressing Toolings Ceramic Rollers: Vesuvius Rollers
Automotive Glass: Automobile Glass Backlites: Rear Glass

Customized Double Curvature Bending Glass Tempering machine for Automotive Backlite / rear glass with gravity mould and pressing mould.

Model: LV-TB-V series





Why Choose Us
flat and curved bending China factory hot sale customized Tempered glass machine

Luoyang Lever Industry Co., Ltd.

A Professional manufacturer of Glass Tempering Plant.
More than 19 years experiences in this Glass Processing Inudstry.
Experienced R&D, and Installation & Service Engineers & Technicians team.
Lifetime maintenance support.

flat and curved bending China factory hot sale customized Tempered glass machine


Detailed Images
flat and curved bending China factory hot sale customized Tempered glass machine

Product Description

Model: LV-TB-V Series, (MOULD BENDING / TOOLINGS BENDING)

Double Curvature Bending Glass Tempering Furnace

Double Curvature Glass Tempering & Bending Furnace

Double Curved Bending Glass Toughening Plant

Doulbe Curvature Glass Toughened Machine

for Automotive Backlites / Rear Glass / Back Windshield Glass / Rear Windshield Glass



1. Machine Application

LV-TB-V Series Double Curvature Bending Glass Tempering Plant is a special plant used to produce the curved tempered glass for automobile backlite glass, also for trucks, furniture, etc. Our customer produced the side doors for BMW, Audi, Toyota, Honda, Hyundai, Peugeot, etc.



2. Popular size for machine models:

DOUBLE BENDING GLASS TEMPERING FURNACE (MOULD BENDING / TOOLINGS BENDING)

Model

Max. Loading Area

(mm)

Min.Glass Size

(mm)

Thickness

(mm)

Max.Depth

(mm)

LV-TB1608V ⌒1600 x ⌒800 ⌒200 x ⌒300 3.5~6 150
LV-TB1809V ⌒1800 x ⌒900 ⌒200 x ⌒300 4~6 150
LV-TB1810V ⌒1800 x ⌒1000 ⌒200 x ⌒300 4~6 150
LV-TB2012V ⌒2000 x ⌒1200 ⌒200 x ⌒300 5~6 150
LV-TB2212V ⌒2200 x ⌒1200 ⌒200 x ⌒300 5~6 300



flat and curved bending China factory hot sale customized Tempered glass machine



2. Supply Scope:

2.1. Loading table

2.2. Heating section

2.3. Double bent Forming section with mould

2.4. Quenching section

2.5. Transmission section

2.6. Cooling section

2.7. Unloading table

2.8. Blower system

2.9. Electrical & control system

2.10. Glass mould (1 set)



3. Popular size:

Model Max. Loading Area Min.Glass Size Thickness Max.Depth
(mm) (mm) (mm) (mm)
LV-TB1608V ⌒1600 x ⌒800 ⌒200 x ⌒300 3.5~6 150
LV-TB1810V ⌒1800 x ⌒1000 ⌒200 x ⌒300 4~6 150
LV-TB2012V ⌒2000 x ⌒1200 ⌒200 x ⌒300 5~6 150
LV-TB2212V ⌒2200 x ⌒1200 ⌒200 x ⌒300 5~6

300



4. Machine Main Features:

4.1. In the bending forming, for transmission of pressing mould, support mould and rollers, we use servo motors & servo controllers.

4.2. In quenching section, for transmission of mould carrier, we use servo motors & servo controllers.

4.3. Equipped with heating & insulating system in forming section, which could keep temperature of the forming section so that the glass is formed in high temperature.

4.4. Easy-making and cheap moulds

4.5. Easy & quick moulds changing-time

4.6. Smaller roller distance in heating oven which guarantee the high quality

4.7. Heating section has a helix matrix structure, which can control the temperature of each area independently. Reasonable design and unique structure of heating elements make a long serve life.

4.8. The heating oven body is full closed and the Insulating materials are of high quality material with top performance which can ensure very lower energy consumption.

4.9. Ceramic roller: World-famous brand

4.10. Ceramic roller driving adopts seamless round belts.

4.11. Fault diagnosis system for the heating elements.
